Thermocouples IEC

Our IEC Thermocouples range offers a comprehensive selection of temperature sensors designed for accurate and reliable measurement across a wide variety of applications. The range includes mineral insulated thermocouples, fine wire exposed junction sensors, moulded-on thermocouples, and fabricated or specialist probes, all manufactured in accordance with IEC colour standards.

We provide sensors in multiple probe styles, diameters and configurations, including fast response probes, surface and magnet-mounted thermocouples, and assemblies with terminal heads or specialised mountings. A wide choice of cable types such as PFA, PTFE and glassfibre, along with various termination options including miniature plugs and bare wire tails, ensures flexibility for different installation and environmental requirements.

In addition, the range includes application-specific solutions such as surface probes, bolt-on and pipe sensors, air and needle probes, and heavy-duty industrial thermocouples, making it suitable for use in industries including manufacturing, HVAC, process control and laboratory testing. Overall, Labfacility’s IEC thermocouples provide a versatile and dependable solution for both general-purpose and specialist temperature measurement needs.

Thermocouples polyvalents jonction expose fil fin IEC

Labfacility propose des cbles en PFA, PTFE et fibre de verre avec diverses terminaisons telles que des fiches de thermocouple miniatures ou des queues de fil nues.

Thermocouples à isolation minérale à réponse rapide IEC

Thermocouples isolés minéraux à réponse rapide de 0,25 mm, 0,5 mm, 0,75 mm et 0,81 mm à réponse rapide dans différents styles.

Thermocouples isolation minrale IEC

Thermocouples de type isol minral durable de 1 mm, 1,5 mm, 3 mm et 6 mm pour sadapter une large gamme de mesures de temprature. Diffrents types, longueurs et diamtres de sondes disponibles.

Thermocouples avec ttes terminales

Thermocouples avec ttes terminales, y compris les thermocouples botier mural isols minralement, de style industriel et distance.

Thermocouples magntiques IEC

Les thermocouples magntiques sont des capteurs de temprature spcialiss utiliss dans des environnements o les thermocouples traditionnels sont confronts des dfis.

Lutilisation daimants facilite galement linstallation et le positionnement, amliorant ainsi la polyvalence et la fiabilit des systmes de surveillance de la temprature.

Les thermocouples magntiques offrent une solution innovante pour les exigences leves en matire de mesure de la temprature.

Thermocouples fabriqus et spcialiss IEC

Thermocouples fabriqus et spcialiss pour sadapter une large gamme dapplications.

Thermocouples fil hermtiquement scells IEC

An IP67 wire thermocouple that is hermetically sealed for use in corrosive or wet environments.
This versatile multi-purpose sensor has been specifically designed for use in and to protect against corrosion in harsh or wet environments. It has a quick response time and can be easily cleaned. The impermeable PFA insulated flexible wire thermocouple provides exceptional resistance to oils, fluids, gases, and chemicals and is electrically isolated.

Offered here in IEC type K, J & T colours, in 1, 2 or 5 m lengths with bare tails or a miniature plug termination option.

Also available in the following versions:

Hermetically Sealed Wire Thermocouple ANSI

Hermetically Sealed Wire RTD Sensors

Cant find what your looking for?

Please complete our custom configurator forms and send us your specific requirements and build your own sensor.

We are specialists in the design and manufacture of custom-built temperature sensors. Quality and Service are key elements in the continued growth of Labfacility; technical support for both sensing and instrumentation is always freely available from our experienced technical sales teams.

Comparison of Sensor Types

	Thermocouple	Platinum Resistance Thermometer	Thermistor
Sensor	Thermoelement, two dissimilar metals/alloys	Platinum-wire wound or flat-film resistor	Ceramic (metal oxides)
Accuracy (typical values)	0.5 to 5.0°C	0.1 to 1.0°C	0.1 to 1.5°C
Long term Stability	Variable, Prone to ageing	Excellent	Good
Temperature range	-200 to1750°C	-200 to 650°C	-100 to 300°C
Thermal response	Sheathed – slow Exposed tip – fast 0.1 to 10 secs typical	Wirewound – slow Film – faster 1-50 secs typical	generally fast 0.05 to 2.5 secs typical
Excitation	None	Constant current required	None
Characteristic	Thermovoltage	PTC resistance	NTC resistance (some are PTC)
Linearity	Most types non-linear	Fairly linear	Exponential
Lead resistance effect	Short cable runs satisfactory	3 & 4 wire – low. 2 wire – high	Low
Electrical “pick-up”	susceptible	Rarely susceptible	Not susceptible
Interface	Potentiometric input. Cold junction compensation required	Bridge 2,3 or 4 wire	2 wire resistance
Vibration effects/ shock	Mineral insulated types suitable	wirewound – not suitable. Film – good	Suitable
Output/ characteristic	From 10µV/°C to to 40µV/°C depending on type	approx. 0.4 W/°C	-4% / °C
Extension Leads	Compensating cable	Copper	Copper
Cost	Relatively low cost	Wirewound – more expensive Film – cheaper	Inexpensive to moderate
